Olympe::RuntimeEnvironment Class Reference

Provides Blackboard variable values and dynamic pin values at runtime. More...

#include <RuntimeEnvironment.h>

Public Member Functions
	RuntimeEnvironment ()=default
void	SetBlackboardVariable (const std::string &key, float value)
	Stores or overwrites a Blackboard variable.
bool	GetBlackboardVariable (const std::string &key, float &outValue) const
	Looks up a Blackboard variable.
bool	HasBlackboardVariable (const std::string &key) const
	Returns true when the given key has been set.
void	SetDynamicPinValue (const std::string &pinID, float value)
	Stores or overwrites the runtime value for a dynamic data pin.
bool	GetDynamicPinValue (const std::string &pinID, float &outValue) const
	Looks up the runtime value of a dynamic data pin.
void	Clear ()
	Removes all stored variables and pin values.

Private Attributes
std::map< std::string, float >	m_blackboardVariables
	Blackboard key -> value.
std::map< std::string, float >	m_dynamicPinValues
	Pin UUID -> value.

Detailed Description

Provides Blackboard variable values and dynamic pin values at runtime.

Acts as the single source of truth for all float data during condition evaluation. Populated before evaluation begins (or updated dynamically as connected nodes provide new data).

Definition at line 36 of file RuntimeEnvironment.h.

Constructor & Destructor Documentation

RuntimeEnvironment()

Olympe::RuntimeEnvironment::RuntimeEnvironment ( )

default

Member Function Documentation

Clear()

void Olympe::RuntimeEnvironment::Clear

(

)

Removes all stored variables and pin values.

Definition at line 57 of file RuntimeEnvironment.cpp.

References m_blackboardVariables, and m_dynamicPinValues.

GetBlackboardVariable()

bool Olympe::RuntimeEnvironment::GetBlackboardVariable	(	const std::string &	key,
		float &	outValue
	)		const

Looks up a Blackboard variable.

Parameters

key	Variable identifier.
outValue	Receives the value when found.

Returns

true when the key exists; false otherwise.

Definition at line 21 of file RuntimeEnvironment.cpp.

References GetComponentTypeID_Static(), and m_blackboardVariables.

Here is the call graph for this function:

GetDynamicPinValue()

bool Olympe::RuntimeEnvironment::GetDynamicPinValue	(	const std::string &	pinID,
		float &	outValue
	)		const

Looks up the runtime value of a dynamic data pin.

Parameters

pinID	Pin UUID.
outValue	Receives the value when found.

Returns

true when the pin ID exists; false otherwise.

Definition at line 44 of file RuntimeEnvironment.cpp.

References GetComponentTypeID_Static(), and m_dynamicPinValues.

Here is the call graph for this function:

HasBlackboardVariable()

bool Olympe::RuntimeEnvironment::HasBlackboardVariable

(

const std::string &

key

)

const

Returns true when the given key has been set.

Parameters

key	Variable identifier.

Definition at line 30 of file RuntimeEnvironment.cpp.

References GetComponentTypeID_Static(), and m_blackboardVariables.

Here is the call graph for this function:

SetBlackboardVariable()

void Olympe::RuntimeEnvironment::SetBlackboardVariable	(	const std::string &	key,
		float	value
	)

Stores or overwrites a Blackboard variable.

Parameters

key	Variable identifier (e.g. "mHealth").
value	Float value to associate with the key.

Definition at line 16 of file RuntimeEnvironment.cpp.

References GetComponentTypeID_Static(), and m_blackboardVariables.

Referenced by Olympe::Examples::Example1_SimpleHealthCheck(), Olympe::Examples::Example3_ConditionChainAND(), Olympe::Examples::Example4_ConditionChainOR(), Olympe::Examples::Example5_ComparisonOperators(), and Olympe::GraphRuntimeInstance::SetBlackboardVariable().

Here is the call graph for this function:

Here is the caller graph for this function:

SetDynamicPinValue()

void Olympe::RuntimeEnvironment::SetDynamicPinValue	(	const std::string &	pinID,
		float	value
	)

Stores or overwrites the runtime value for a dynamic data pin.

Parameters

pinID	Pin UUID (matches DynamicDataPin::id or NodeConditionRef::leftPinID / rightPinID).
value	Float value delivered by the connected node.

Definition at line 39 of file RuntimeEnvironment.cpp.

References GetComponentTypeID_Static(), and m_dynamicPinValues.

Referenced by Olympe::GraphRuntimeInstance::SetDynamicPinValue().

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

m_blackboardVariables

std::map<std::string, float> Olympe::RuntimeEnvironment::m_blackboardVariables

private

Blackboard key -> value.

Definition at line 96 of file RuntimeEnvironment.h.

Referenced by Clear(), GetBlackboardVariable(), HasBlackboardVariable(), and SetBlackboardVariable().

m_dynamicPinValues

std::map<std::string, float> Olympe::RuntimeEnvironment::m_dynamicPinValues

private

Pin UUID -> value.

Definition at line 97 of file RuntimeEnvironment.h.

Referenced by Clear(), GetDynamicPinValue(), and SetDynamicPinValue().

---

The documentation for this class was generated from the following files:

• Source/Runtime/RuntimeEnvironment.h
• Source/Runtime/RuntimeEnvironment.cpp
